I’ve been setting up and tearing down Kubernetes clusters for testing various things for the past year, mostly using Vagrant/Virtualbox but also some VMware vSphere and OpenStack deployments.

I wanted to set something a little more permanent up at my home lab — a cluster where I could add and remove nodes, run nodes on multiple physical machines, and use different types of compute hardware.

Set up the virtual machines

To get started I used a desktop System76 Wild Dog Pro Linux box (4.5 GHz i7-7700K, 64GB DDR4) and my create-vm script to create six Ubuntu 18.04 “Bionic Beaver” VMs for the cluster:

for n in $(seq 1 6); do
    create-vm -n node$n \
      -i ./ubuntu-18.04-server-amd64.iso \
      -k ./ubuntu.ks \
      -r 4096 \
      -c 2 \
      -s 40
done

With these parameters each VM will have 4GB RAM, 2 VCPUs, and a 40GB hard drive.

Install and configure Kubespray

I cloned Kubespray into a directory and created an Ansible inventory file following the instructions from the README.

git clone git@github.com:kubernetes-sigs/kubespray.git
cd kubespray
pip install -r requirements.txt
rm -Rf inventory/mycluster/
cp -rfp inventory/sample inventory/mycluster
declare -a IPS=($(for n in $(seq 1 6); do get-vm-ip node$n; done))
CONFIG_FILE=inventory/mycluster/hosts.ini \
  python3 contrib/inventory_builder/inventory.py ${IPS[@]}

The get-vm-ip script is in the same repo as the create-vm script, and both are described in my Use .iso and Kickstart files to automatically create Ubuntu VMs article.

The inventory.py script generates an Ansible hosts inventory file in inventory/mycluster/hosts.ini with all of your VM IP addresses.

I like to add one variable override to the bottom of hosts.ini which copies the kubectl credentials over to my host machine. That way I can run kubectl commands directly from my desktop. The extra lines to add to the bottom of hosts.ini are:

[all:vars]
kubectl_localhost=true

Install Kubernetes

To install Kubernetes on the VMs I run the Kubespray cluster.yaml playbook:

export ANSIBLE_REMOTE_USER=ansible
ansible-playbook -i inventory/mycluster/hosts.ini \
    --become --become-user=root cluster.yml

Once the playbooks have finished, you should have a fully-operational Kubernetes cluster running on your desktop.

At this point you should be able to query the cluster from your desktop using kubectl. For example:

$ kubectl cluster-info
Kubernetes master is running at https://192.168.122.251:6443
coredns is running at https://192.168.122.251:6443/api/v1/namespaces/kube-system/services/coredns:dns/proxy
kubernetes-dashboard is running at https://192.168.122.251:6443/api/v1/namespaces/kube-system/services/https:kubernetes-dashboard:/proxy
To further debug and diagnose cluster problems, use 'kubectl cluster-info dump'.

$ kubectl get nodes
NAME    STATUS   ROLES         AGE    VERSION
node1   Ready    master,node   3d6h   v1.13.0
node2   Ready    master,node   3d6h   v1.13.0
node3   Ready    node          3d6h   v1.13.0
node4   Ready    node          3d6h   v1.13.0
node5   Ready    node          3d6h   v1.13.0
node6   Ready    node          3d6h   v1.13.0

$ kubectl get pods --all-namespaces
NAMESPACE          NAME                                           READY   STATUS      RESTARTS   AGE
kube-system        calico-kube-controllers-67f89845f-6zbvx        1/1     Running     1          3d6h
kube-system        calico-node-jh7ng                              1/1     Running     2          3d6h
kube-system        calico-node-l9vfb                              1/1     Running     2          3d6h
kube-system        calico-node-mqxjx                              1/1     Running     2          3d6h
...

Set up the Kubernetes Dashboard

One of the first things I like to do is set up access to the Kubernetes dashboard. First I set up a service account for the admin user:

$ cat ~/Projects/k8s-cluster/dashboard-adminuser.yaml
---
apiVersion: v1
kind: ServiceAccount
metadata:
  name: admin-user
  namespace: kube-system

---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: admin-user
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: cluster-admin
subjects:
- kind: ServiceAccount
  name: admin-user
  namespace: kube-system

$ kubectl apply -f ~/Projects/k8s-cluster/dashboard-adminuser.yaml

Next I get the bearer token for the user account:

$ kubectl -n kube-system describe secret $(kubectl -n kube-system get secret | grep admin-user | awk '{print $1}')

Finally I plug the dashboard URL that I got from kubectl cluster-info into my browser, select “Token” authentication, and cut and paste in the bearer token to log into the system.

Once logged in, an overview of my cluster pops up:

With a minimal amount of working compute infrastructure, it’s easy to set up your own production-quality Kubernetes cluster using Kubespray.

Hope you find this useful.
